| Basic Information | ||
|---|---|---|
| Model | MGO-W3KLE-Li Ion-HF | |
| Capacity | 3 KVA | |
| Input | ||
| Voltage Range | 120–300 Vac | |
| Frequency Range | 45-66 automatically select synchronization range according to power frequency |
|
| Power Factor | ≥ 0.99 | |
| Output | ||
| Voltage | 220/230/240 Vac |
|
| Power Factor | ≥ 0.99 | |
| Voltage Regulation | ±1% | |
| Output Frequency | 50/60 Hz ± 0.5% | |
| Crest Factor | 3:1 | |
| Transfer Time | 0 ms (AC to Battery), 4 ms (Inverter to Bypass) |
|
| Type of wave | Pure Sine Wave | |
| Battery | ||
| DC Voltage | 48Vdc | |
| Others | Rack-mount external Charger 4 Amp (can be extended) |
|
| Environment | ||
| Temperature | 0 ~ 40°C | |
| Humidity | 0 ~ 95% (Non-condensing) | |
| Noise Level | ≤ 50 dB (at 1 meter) | |
| Communication | ||
| Interface | RS232(USB, SNMP,dry contact is optional) | |
| Warranty | ||
| Warranty Details | 1 Year | |
