| General Information | ||
|---|---|---|
| Type | Maintenance Free-Sealed Lead Acid Battery | |
| Capacity | 80Ah | |
| Input Voltage | 12V | |
| Max. Charging Current | 8A / 24A | |
| Resistance | Approx. 6.2 mΩ | |
| Terminal | M6 | |
| Max. Discharge Current | 720A (5 sec.) | |
| Self Discharge | 3 Months: Remaining Capacity: 91% 6 Months: Remaining Capacity: 82% 12 Months: Remaining Capacity: 65% |
|
| Floating Life | 10 Years | |
| Operating Temperature | Nominal Operating Temperature: 25°C±3°C (77°C±5°C) Discharge: -15°C ~ 50°C (5°F ~ 122°F Charge: 10°C ~ 50°C (14°F ~122°F) Storage: -20°C ~ 50°C (-4°F ~122°F) |
|
| Others | Float charging voltage (25°C): 13.50 to 13.80V Cyclic charging voltage (25°C): 14.4V to 15V |
|
| Physical Information | ||
| Weight | 22 Kg ± 3% | |
| Material | Terminal material: Copper | |
| Dimension | 255±2 (L) x 167±2mm (W) x 210±2mm (H) Total Height: 215±2mm |
|
| Warranty Information | ||
| Warranty | 1 Year | |
