| Basic Information | ||
|---|---|---|
| Capacity | 20KVA | |
| Load Capacity | 105%~129% for 60s；130%~150% for 30s；Above 150% for 300ms | |
| Input Voltage Range | 120Vac-288Vac | |
| Output Voltage | 220/230/240± 1% | |
| Output Frequency | 50/60±0.5% (Battery Mode) | |
| Noise Level | <55 (within 1 meter) | |
| Battery | 192 Vdc | |
| Input Features | ||
| Voltage range (Vac) | 120Vac-288Vac | |
| Frequency (HZ) | 45～70 Hz | |
| Phase | Single Phase | |
| Power Factor | Full load ≥0.99 | |
| Output Features | ||
| Power Factor | 0.9 | |
| Voltage(V) | 220/230/240±1% | |
| Transfer Time | 0 ms | |
| Others | ||
| Display | LED display UPS work status, LCD display UPS work parameters | |
| Alarm | Battery low-voltage, mains abnormal, overload, UPS fault, over temperature protection | |
| Protection | Protection: Input over-voltage protection, Lighting/Surge protection, Battery overcharging protection, Overload protection, Overheating, Deep discharge, Short circuit protection. | |
| Manufacture Warranty | ||
| Warranty | 01 year | |
